PyroSim is a graphical user interface for the Fire Dynamics Simulator (FDS). It is used to create fire simulations that accurately predict smoke movement, temperature, and toxin concentrations during a fire.

123►

To see some real-world examples of PyroSim in action, please visit the PyroSim Gallery.

To see where PyroSim is being used around the world, you can view our Customers Map.

Key Features

PyroSim 2011 is a graphical user interface for version 5 of FDS and Smokeview. Some of PyroSim’s key features include:

• Edit geometry using floor plan images, angled walls, and other powerful tools.
• Integrated execution of FDS and Smokeview
• Full support for 64-bit operating systems
• Run multi-CPU simulations with a single click
• Import existing FDS4 and FDS5 models.
• Convert FDS4 input files to FDS5
• Import AutoCAD DXF models directly or as background images.

For a list features and bug fixes new in PyroSim 2011, please read the Release Notes.

Download the PyroSim Slideshow to learn more about PyroSim’s capabilities.

PyroSim is designed to run on MS Window operating systems. Apple users have reported success using PyroSim with both VMWare Fusion and Parallels.

To assist users in making informed estimates about the run-time and memory requirements of models with similar properties, please see the page detailing our benchmarking for PyroSim and FDS_5.

Verification and Validation

The developers of FDS at the National Institute of Standards and Technology (NIST) use the model verification and validation techniques outlined in ASTM E 1355 to ensure the accuracy of the numerical solutions given by FDS. Additional information on Verification and Validation of FDS can be found in Volume 2 and Volume 3 of the FDS Technical Reference Guide.

FDS was also the subject of a verification and validation study sponsored by the US Nuclear Regulatory Commission and the Electric Power Research Institute. This work compares 5 different simulators based on several fire scenarios.

Verification and Validation of Selected Fire Models for Nuclear Power Plant Applications (NUREG-1824, Vols 1-7)

Buy PyroSim

For more information about PyroSim licensing, please visit our licensing information page, or order online. You can also contact a local distributor for additional information.
